EEU-MR16-LED
EEU-MR16-LED
$0.00
• Sleek, compact design
• Designed for ceiling and wall installation
• Part of Astralite’s quick ship program
• UV-stabilized thermoplastic housing with a UL 94 V-0 rating
• Utilizes (2) high-efficiency 1W LED emergency heads
• Nickel-Cadmium battery is standard, and provides a minimum of 90 minutes of illumination in emergency mode
• Meets UL 924, NFPA 101, NEC and OSHA illumination standards.
• 5-year warranty on housing and electronics
Letter Color:
Housing Color:
Remote Capacity:
Quantity:
FEATURES
- Contractor’s choice EXIT-EM combo
- Sleek, compact design
- Designed for ceiling and wall installation
- Optional remote capability: choice of 3W or 10W at 6V
- Fast, easy installation
- Part of Astralite’s quick ship program
CONSTRUCTION
- UV-stabilized thermoplastic housing with a UL 94 V-0 rating
- Field-selectable universal snap-in directional indicators
- EXIT letters are 6” tall with ¾” stroke; 100 ft viewing distance
LAMP
- Utilizes (2) high-efficiency 1W LED emergency heads
- High-quality LEDs mounted on a printed circuit board provide uniform diffused illumination for 6” high letters with 3/4” stroke
Electronics
- Dual-voltage input capability: 120/277V
- Brownout protection
- Low-voltage disconnect
- AC indicator light with test switch
Battery
- Nickel-cadmium battery is standard
- Provides a minimum of 90 minutes of illumination in emergency mode
- Operating temperature range: 10-40°C
Compliance
- ETL listed. Meets UL 924, NFPA 101, NEC and OSHA illumination standards
Warranty
- 5-year warranty on housing and electronics. Battery is prorated
