DCA-200-LED
DCA-200-LED
$0.00
Letter Color:
Housing Color:
Lamp Option:
Options:
Quantity:
FEATURES
- Die cast aluminum EXIT-EM combo unit
- Single face only; designed for wall mounting
CONSTRUCTION
- Extruded aluminum construction
- Field selectable chevron directional indicator offers a choice of direction on-site
- EXIT letters are 6” tall with ¾” stroke; 100 ft viewing distance
LAMP
- Utilizes two high-efficiency 1W or 3W LED heads in emergency mode; higher wattage lamps are available upon request, consult factory for more options
- EXIT letters illuminated by long-lasting high-output AlInGaP LEDs with a rated life of 10+ years
Electronics
- Dual-voltage input capability: 120/277V
- Low-voltage disconnect
- AC indicator light with test switch
- Brownout protection
Battery
- Lead-acid battery is standard, nickel-cadmium battery offered as an option
- Provides a minimum of 90 minutes of illumination in emergency mode
- Operating temperature range: 0° C to 40° C
Compliance
- Meets and or exceeds UL 924, NFPA, NEC, and OSHA illumination standards
Warranty
- 5 year warranty on housing and electronics. Battery is prorated
