FEATURES

• Extruded aluminum edgelit EXIT-EM combination unit

• Designed for surface mounting

CONSTRUCTION

• Extruded aluminum construction with a die-cast mounting plate

• Field-selectable chevron directional indicator offers a choice of direction on-site

• Heads are constructed of UV stable thermoplastic

• Features a choice of 6” or 8” EXIT letters; 100ft viewing distance

LAMP

• Utilizes two 1W LED adjustable heads in emergency mode; contact factory for additional lamp options

• Exit face is illuminated by long-lasting high-output AlInGaP LEDs with a rated life of 10+ years

ELECTRONICS

• Dual-voltage input capability: 120/277V

• Low-voltage disconnect

• AC lockout installation

• Brownout protection

• AC indicator light with test switch

BATTERY

• Nickel-cadmium battery comes standard

• Operating temperature range: 0° C to 40° C




• Provides a minimum of 90 minutes of illumination in emergency mode

COMPLIANCE

• Meets or exceeds UL 924, NFPA 101, NEC and OSHA illumination standards

WARRANTY

• 5-year warranty on housing and electronics. Battery is prorated
