FEATURES

• NEMA 4x high-capacity emergency unit

• Remote capability: 125, 150, or 200W unit capacity

• Designed for indoor or outdoor use

CONSTRUCTION

• Constructed from UV-stabilized UL 94-5VA flammability-rated PC/PBT blended plastic

• Mounted with four flange-style feet

LAMP

• Choice of no heads, two heads, or three heads

• Side or top mounted PAR36 lamp heads; can be ordered with steel lamp housing

ELECTRONICS

• Dual-voltage input capability: 120/277V

• Low-voltage disconnect

• AC lockout installation

• Brownout protection

BATTERY

• Lead-acid battery is standard, and provides a minimum of 90 minutes of illumination in emergency mode

• Operating temperature range: 10-40° C

COMPLIANCE

• Meets IP65 of IEC529 and NEMA 1, 2, 4, and 4x specifications

• UL listed to UL508-4x requirements

WARRANTY

• 5-year warranty on housing and electronics. Battery is prorated
