EEU-Q
Thermoplastic Exit-EM Combo
FEATURES
Thermoplastic EXIT-EM combination unit with krypton lamps
Universal mounting canopy for top installation
Optional remote capability: 10W at 6V
Fast, easy installation
Part of Astralite’s quick ship program
CONSTRUCTION
UV-stable, impact-resistant thermoplastic housing; meets UL94V-0 flame rating
Features universal snap in and out chevrons
EXIT letters are 6” tall with ¾” stroke; 100 ft viewing distance
LAMP
Uses two 6W krypton lamp heads with full adjustability in emergency mode
Includes down light
Long-lasting high-output AlInGaP LEDs illuminate the EXIT face
ELECTRONICS
Dual-voltage input capability: 120/277V
Brownout protection
Low-voltage disconnect
AC indicator light with test switch
BATTERY
Lead acid battery is standard
Provides a minimum of 90 minutes of illumination in emergency mode
Operating temperature range: 10-40° C
COMPLIANCE
ETL listed. Meets UL 924, NFPA 101, NEC and OSHA illumination standards
WARRANTY
5-year warranty on housing and electronics. Battery is prorated
